Leica Lino L6R Horizontal and Vertical Laser

£475 ex VAT

The Leica Lino L6R is a self-leveling red multi line laser with 360° laser line projection for multi-directional alignment—perfect for indoor applications. The laser’s vertical lines are easily adjusted (± 10°) once the plumb point is set.


  • Horizontal and two vertical 360 red laser lines
  • High visibility due to red Ultra-power laser diodes
  • Self-levelling over wide range
  • Fixed plumb point due to integrated base
  • Adjustable strength of laser lines
  • Operating range of up to 25m
  • Li-ion power for up to 36hr operation
  • Uninterrupted working with Triple-Power concept
  • Smart magnetic adapters for easy positioning

Supplied With:

  • Leica Lino L6R l Rugged case
  • Li-Ion battery pack includes charged and plugs l Alkaline battery tray
  • TWIST 250 magnetic multi-functional adapter l UAL 130 wall-mount adapter l Laser target
  • Safety instructions l Calibration certificate
  • Quick start guide l Warranty card
  • 3 year warranty

Levelling accuracy
Self-levelling range
Self-levelling time
Intersectional points
Beam direction
Laser line width at 5m
Laser type
Battery type
Operating time
Protection class

Weight with batteries

Tripod thread Lino

up to 25 m* (70 m with receiver)
± 0.2 mm / m
± 4 °
< 3 s
up, down, right, left, front, back (90° / 180°)
Horizontal 360° | Vertical 2 x 360°
< 2 mm
635 nm / class 2 (red)
Lino Li-Ion battery pack 5200 mAh / 18.7 Wh or 3xAA Alkaline
< 36h
IP 54
110 × 60 × 100 mm

781 g

1/4 in (5/8 in with adapter)

3 Year Manufacturer’s Warranty

Summary of Leica DISTO Manufacturers Warranty


3 year warranty

LEICA Geosystems AG (LEICA Geosystems), warrants to the original end user (Customer) that this DISTO Product will be free from defects in workmanship and materials, under normal use three (3) years shall apply, and (ii) batteries for which ninety (90) days shall apply, unless such warranty period has been extended by LEICA Geosystems, and provided any and all operating and maintenance instructions are strictly respected, in particular in case of extreme and/or continuous applications/use of the Product.

The warranty period begins on the proved purchase date (or if applicable, date of delivery or date of acceptance report). LEICA Geosystems sole obligation under this express warranty shall be, at LEICA Geosystems sole option and expense, to replace or repair the Product or part, or refund the purchase price paid for the Product. LEICA Geosystems warrants any repaired or replaced Product or part for a period of ninety (90) days from shipment, or through the end of the original warranty, whichever is longer. All Products or parts that are replaced become the property of LEICA Geosystems. This express warranty does neither cover consumables, such as reflectors, bulbs and fuses, nor third party products.
For full details contact Leica Geosystems, or go to

Limitation of liability

Leica Geosystems also excludes any liability, whether based in contract or tort (including negligence), for incidental, consequential, indirect, special, or punitive damages of any kind, or costs of procurement of substitute products by customer, or for the loss of revenue or profits, loss of business, loss of information or data, or other information or financial loss arising out of or in consequence with the sale, installation, maintenance, use, performance, failure, or interruption of this product, even if Leica Geosystems or its distributors have been advised of the possibility of such damages, and limits its liability to replacement, repair, or refund of the purchase price paid, at Leica Geosystems option. This limitation of liability for damages will not be affected if any remedy provided herein shall fail of its essential purpose.


To claim your 3 year warranty you can register your DISTO on the Leica Geosystems website. The warranty extension is valid only if the device has been registered with  within 8 weeks of purchase
